Model:EK-T3KVA-220V
Power Rating:3KVA/2.4KW
Input low/high voltage: 165V-275V
Frequency: 46Hz-74Hz (adjustable)
Output:Voltage 220/230V
Battery type: 4x 12V-7Ah, sealed lead acid
Backup time: 8 mins - 30 mins
Description
Model: Ekimp EK-T3KVA -220V 1/1 True Online Double Conversion 3 D printer online ups
Power rating: 3KVA/2.4KW
INPUT
· Voltage 220V/230V
· Input low/high voltage 165V-275V
· Frequency 46Hz-74Hz (adjustable)
· Power factor 0.99
BATTERY/CHARGER
· Battery type 2x 12V-7Ah, sealed lead acid
· Backup time 8 mins - 30 mins
OUTPUT
· Voltage 220V/230V (Fixed)Single phase
· Voltage stability ± 2%
· Power factor 0.8
· Voltage distortion ≤ 3% at linear load
· Transfer time 0 ms
· Frequency 50Hz ± 2%
· Output waveform Pure sinewave
· Overload @0.9pf load 125%-60secs, 135%-30secs, >135%-100msec (trf to bypass)
· Efficiency >92%
DISPLAY/INTERFACE
· LCD display AC/DC; KVA; Freq; Temp; Battery & load level
· LED status indicator Utility power; Battery discharge; Inverter On
· External comm. RS232
· Communication S/W Windows; Linux; Unix
