Hybrid 48V 8.2KW Solar inverter

EKOG-8.2kva
Solar inverter 48V 8200W off grid
Output range voltage:200/230/240VAC
Frequency:49~51 Hz
Max current:500VAC
Range of input 90~450V
MPPT built in
Touch screen
ISO/Android wifi or GPRS
Max PV Charging 160A
Smart lot:RS232/WIFI/Remove LCD/GPRS

Solar inverter 48V 8200W 8.2K off grid inverter also can on grid 90~450V super wide voltage input

48V 8200W off grid inverter Feature

1.pure sina wave solar inverter(off grid/on grid)

2.Power factor:1.0

3.Application ISO and Android wifi or GPRS

4. Working without battery

5.One button recover to Original

6.Built in Lithium battery Activation

7.Built in 160A MPPT Controller

8. Battery Board input voltage range:90~450VDC

9.Built in dust proof parts,suitable badlly envirement

10. Smart battery charging designed. improving the battery lifespan

11. Double output

12. Touch screen

48V 8200W off grid inverter Data specification

Item No.	EKOG-8200Kva
Rate Output	8200W
Max PV charging Current	160A
Max DC current	360VDC
Voltage of starter/Feeback voltage	90VDC/120VDC
Voltage of MPPT	90~450VDC
MPPT Tracking point/Max input current	1/27A
Output Voltage	220/230/240V AC
Range of output voltage	195~253VAC
Power Factor	>0.99
Output Current	35.6A
Max transmit effective(DC/AC)	98%
